Front | Back |
What is this? |
Pink-pyriform lobe, red-rhinal sulcus, yellow-abducens nerve (from medulla oblogata-6), teal-glossopharyngeal nerve 9. green-vagus nerve 10, purple-spinal acessory nerve 11, organe- trochlear nerve 4
|
What is this? |
Red-trigeminal nerve, on left green-fascial 7, on right blue is abducens-6
|
What is this? |
Teal-medulla oblongate, purple-pons, green-occulomotor nerve 4, blue- optic tract, red-optic nerve II, pink-optic chiasm, orange-olf tract and bulb
|
Name 1-5 , do not need to know #2 |
1-cerebellum 2-primary fissure 3-superior colliculus, 4- interferior coliculus, just below 3, 5-pineal gland
|
Name 6-10, do not need to know 7 |
6-habenula, the stria medullaris runs into this, 7-stria medularis, do not need to know, 8-left ventricle, 9-third ventricle, 10-cerebral aqueduct,
|
Name 11-15 do not need 12, 13, 14, 15 |
11- fourth ventricle, 15-fornix
23- septum pellucidium, 24-pons 25- massa intermedia, |
Name 16-20 |
16-hippocampus, 17-mammilary body, 18-part of hypothalmus, ours were cut off, 19-anterior commissure, 20-splenium, means patch!, 20-22-all part of corpus collosum
|
Name 21-26 |
21- genu, 22- splenium 23- septum pellucidium, 24-pons 25- massa intermedia,
|
Name of tree-looking nerves in cerebellum
|
Arbor vitae
|
Where little hole in the top of the head called?
|
Infundibulum
|
Name and number the cranial nerves
|
1-olfactory, 2-optic, 3-oculomotror 4-trochlear, 5-trigeminal, 6-abducens, 7-fascial, 8-auditory 9-glassopharyngeal 10-vagus, 11-spinal accessory, 12- hypoglossal
|
