| Front | Back |
|
Refer to the exhibit. The indicated configuration was established on the HSRP standby router RTB. However, the console message %IP-4-DUPADDR started appearing almost immediately on the RTB router. Given the output of the show standby brief command on RTA, what is the cause of the problem?
|
The group number 50 is missing in the Router RTB configuration commands.
|
|
Which statement correctly explains the process of mitigating ARP attacks on a switch where dynamic ARP inspection (DAI) has been configured?
|
The intercepted packets are verified against the DHCP snooping binding table for valid IP-to-MAC bindings
|
|
Refer to the exhibit. What feature does an SNMP manager need to be able to set a parameter on ACSw1?
|
A manager who is using host 192.168.0.5
|
|
Which statement is true concerning the core layer within the hierarchical design model?
|
Routing should be configured without traffic filtering, address translation, or other packet manipulation at the core.
|
|
When a port security violation occurs on a switch port, the switch sends a syslog message but does not shut down the port. What port security mode is in effect?
|
Restrict
|
|
Which three steps are required to configure interfaces as routed ports on a multilayer Catalyst switch? (Choose three.)
|
Enable IP routing globally.Assign IP addresses to routed ports.Disable Layer 2 functionality on interfaces that will be configured as routed ports.
|
|
A bridging loop occurs in a network and disrupts user connectivity. What action should be taken by a network administrator to restore connectivity?
|
Disable ports that should be in the blocking state.
|
|
Which three actions can cause problems with a VTP implementation? (Choose three.)
|
|
 |
Switch DLS1 is not the root bridge for VLAN 1.The Cost column in the lower part of the exhibit is not the cumulative root path cost.
|
|
Which QoS requirement should be taken into account when implementing VoIP in a campus environment?
|
The QoS requirements should accommodate the smooth demand on bandwidth, low latency, and delay for voice traffic.
|
|
When troubleshooting GLBP in an environment with a VLAN that spans multiple access layer switches, a network engineer discovers that suboptimal paths are being used for upstream traffic. What is the recommended solution?
|
Use HSRP instead of GLBP.
|
